Technical specifications
| Input frequency | 50/60 Hz |
| UPS operating temperatures | 0°C ÷ 40°C |
| Power (kVA) | 5 |
| Input power factor | >0,99 |
| Technology | TRUE ON LINE Double conversion |
| Classification | VFI-SS-111 (EN 62040-3) |
| Power range | 5 kVA |
| Number of phases | 1:1 |
| Model | ZRM 1 |
| Power | 1000 VA/ 900 W |
| Number of input : output phases | 1:1 |
Entry
| Voltage (V) | 220 / 230 / 240 VAC |
| Voltage range | 100 – 275 V |
| Frequency (Hz) | 50/60 Hz |
| Frequency range | 40 – 70 Hz |
| THDi | <3% |
| Input power factor. | ≥0,99 |
Exit
| Voltage (V) | 220 / 230 / 240 VAC |
| Output power factor | 1,0 |
| Static/dynamic voltage regulation | ±1% / ±3% |
| Frequency (Hz) | 50 / 60 Hz ± 3 Hz |
| THDU | max. 5% |
| Overload capacity inverter | 110% – 10 min., 130% – 1 min., > 130% – 1 sec. |
| Efficiency in On-line mode | >95% |
| Eco mode yield | 99% |
| Terminal plate | yes |
| Peak factor | 3:1 |
Batteries
| Model | Lead-acid complies with UL 1778. |
| Autonomy at 100% load | 4,5 minute |
| Scalability | possibility to add modules |
| Cold start | yes |
| Connector for external batteries | yes |
| Loading time | 3 hours at 90% capacity (configurable) |
Weight and dimensions
| UPS dimensions and weight (W x D x H) | 438 x 665 x 88 (2U) |
| Dimensions and weight of battery module (W x D x H) | 438 x 630 x 133 (3U) |
| Weight ( Kg) | 80 |
Communications
| Operation indicator | LCD + LED indicators, sound alarm yes video configurable |
| Communications | Standard: USB, DB-9 RS-232, RJ-45 10/100 Base-T, TVSS, Slot inteligent, REPO Valgfrit: Kort AS400, Carde SNMP |
Ambient
| Noise level | <50 dB |
| Operating temperature for UPS | 0°C ÷ 40°C |
| Recommended operating temperature for UPS | 15°C ÷ 25°C |
| Storage temperature | -25°C ÷ 55°C |
| Humidity | 0 ÷ 95% (non-condensing) |
| Varmeafgivelse | 1000 BTU/h. |
Certification test
| Standards | EN 62040-2:2005, EN 62040-2:2006 |
| Safety | IEC62040-1-1, CE, 62040-3 :2001 |
Options
| SNMP cards |
| Ambient sensor (EMD) |
| Bypass maintenance |
| REPO |
| Cards AS400 |
| Ekstra batteritilstand |
| Kit on 19″ saddle |
| Outlet plug fixing piece |
